Airvolution™ Series
Single and Multi-Split
Reverse Cycle Air Conditioner
The ideal solution to cool or heat just one room, or multiple rooms, of the home or office
The Braemar Airvolution™ Series
Wall mounted split system air conditioning is the ideal solution to cool or heat just one area or room of the home or office
Braemar Airvolution™ split systems come in 5 capacities, to efficiently cool or heat any room – from the study to large open plan living spaces. Inverter technology, standard across the range, helps to reduce energy consumption, so you can relax in comfort all year round.
Split systems are a cost effective way to heat and cool one room in your home. The Braemar range comes in a number of capacities, to suit small studies, right up to large open plan living spaces. Installation costs are generally much lower than for ducted systems, making split systems an attractive choice for budget conscious home owners who still want efficient, quick heating and cooling in single rooms, to large spaces.
The Airvolution™ series also has the new Zoned Energy Rating Label (ZERL). This helps consumers to make a more energy efficient choice based on the unit’s performance in their location’s climate.
For more information on ZERL and how to read the label, please visit:
www.seeleyinternational.com/seeley-learning-centre/zerl/
Indoor Units
- Standard white finish for contemporary look.
- Available in 5 sizes for domestic and
commercial use. Unit can be installed in small homes
and large spaces. - Dry connection available for gate-card or
remote on/off, great for schools or hotels. - Anti-corrosion coating on printed circuit boards
to protect electronics.
Outdoor Units
- Flexible outdoor placement long pipe runs (up to 25m)
- Gold fin advanced protection from the elements
- Slim design allows more flexibility in placing outdoor units
- Dred demand response enabled device capability is standard
- R32 refrigerant high efficiency
Single and Multi-Split Indoor Units
| Model | Zerl Star Rating (Cooling) | Zerl Star Rating (Heating) | Sound Pressure Level (dB) | Sound Power Level (dB) | Airflow l/s (m3/hr) | Width (mm) | Depth (mm) | Height (mm) | Unit |
|---|---|---|---|---|---|---|---|---|---|
| WSHV25D1T | 5.0/4.0/4.5 | 3.0/2.5/2.0 | 21 - 40 | 54 | 175 (630) | 849 | 215 | 289 | Indoor |
| WSHV35D1T | 4.0/3.5/4.0 | 4.0/3.5/4.0 | 24 - 43 | 58 | 189 (680) | 849 | 215 | 289 | Indoor |
| WSHV50D1T | 4.0/3.5/3.5 | 3.0/2.5/2.0 | 24 - 48 | 63 | 264 (950) | 970 | 225 | 300 | Indoor |
| WSHV70D1T | 3.5/3.0/3.5 | 3.0/2.5/2.0 | 32 - 49 | 63 | 334 (1200) | 1080 | 245 | 325 | Indoor |
| WSHV85D1T | 4.5/4.0/4.0 | 3.5/2.5/2.0 | 32 - 49 | 65 | 361 (1300) | 1075 | 246 | 333 | Indoor |
Single Split Outdoor Units
| Model | Zerl Star Rating (Cooling) | Zerl Star Rating (Heating) | Cooling Capacity (kW) | Heating Capacity (kW) | Sound Power Level (dB) | Width (mm) | Depth (mm) | Height (mm) | Unit |
|---|---|---|---|---|---|---|---|---|---|
| WCHV25D1T | 5.0/4.0/4.5 | 3.0/2.5/2.0 | 2.4 | 3 | 61 | 732 | 330 | 555 | Outdoor |
| WCHV35D1T | 4.0/3.5/4.0 | 3.0/2.5/2.0 | 3.45 | 3.73 | 61 | 732 | 330 | 555 | Outdoor |
| WCHV50D1T | 4.0/3.5/3.5 | 4.0/3.5/3.5 | 5.2 | 5.5 | 68 | 970 | 225 | 300 | Outdoor |
| WCHV70D1T | 3.5/3.0/3.5 | 3.5/3.0/3.5 | 7.1 | 7.1 | 68 | 958 | 402 | 660 | Outdoor |
| WCHV85D1T | 4.5/4.0/4.0 | 4.5/4.0/4.0 | 8.5 | 9 | 71 | 1000 | 427 | 746 | Outdoor |
Multi-Split Outdoor Units
| Model | Cooling Capacity Range (kW) | Heating Capacity Range (kW) | Cooling Capacity (kW) | Heating Capacity (kW) | Sound Pressure Level (dB/h) | Width (mm) | Depth (mm) | Height (mm) | Unit |
|---|---|---|---|---|---|---|---|---|---|
| NCHV53D12 | 2.14 ~ 5.80 | 2.58 ~ 5.92 | 5.24 | 5.3 | 55 | 908 | 378 | 602 | Outdoor |
| NCHV72D13 | 2.30 ~ 10.00 | 3.65 ~ 10.00 | 7.15 | 8.6 | 51 | 1001 | 427 | 790 | Outdoor |
| NCHV80D14 | 2.30 ~ 10.25 | 3.65 ~ 10.25 | 8 | 8.9 | 51 | 1001 | 427 | 790 | Outdoor |
| NCHV10D14 | 2.50 ~ 10.30 | 3.13 ~ 12.00 | 10.4 | 10.8 | 60 | 1001 | 427 | 790 | Outdoor |
| MCHV11D15 | 2.60 ~ 12.00 | 2.60 ~ 13.00 | 11.4 | 12 | 61 | 1098 | 440 | 1103 | Outdoor |
- Download Product Brochure
- Download Zone Controller Manual
- Braemar Reverse Cycle MSHV Owner Manual English
- Braemar Reverse Cycle KSHV Owner Manual English
- Braemar Reverse Cycle BSHV Owner Manual English
- Braemar Reverse Cycle LSHV Owner Manual English
- Braemar Reverse Cycle WSHV Owner Manual English
- Braemar Reverse Cycle WSHVT Owner Manual English
For complete peace of mind, Seeley International backs every one of its air conditioning systems with an industry leading comprehensive warranty program.
5 Year Comprehensive Warranty
Quality that lasts – 5 year comprehensive manufacturer’s warranty
Harness the power power of Braemar Reverse Cycle Air Conditioning
A reputation built on quality and endurance
Founded in 1938, Braemar remains one of Australia’s most recognised and trusted brand names today.
Braemar warms the hearts and homes of Australians, providing total climate control in every home.
Zone Controller for Reverse Cycle Systems
Smart, sophisticated and incredibly intuitive, Braemar Zone Control makes operating your Braemar air conditioner so simple. The discreet and modern design will blend seamlessly into the decor of your home.
