Braemar Ecostar® 4 Star Ducted Gas Heaters
Easy to operate, Proven reliability, Zoned-heating capable.
The Braemar Ecostar® 4 Star Series
Ducted gas heating is the easiest, most comfortable way to heat your entire home.
A ducted gas heater is a whole of home solution that allows you to heat the whole house using just one system. It works by taking air from within the house, heating it then distributing through a series of duct work and outlets in the roof.
- MagIQtouch® controller
- Zoned-heating capable
- Braemar add-on cooling system available for model numbers TQ4X20, TQ4X25 and TQ4X30
- Stealth® Softair® fan system
| Model | Star Rating* | Output (kW) | Gas Rate (Mj/h) | Airflow (L/sec) | Width (mm) | Length (mm) | Height (mm) | Gas Type |
|---|---|---|---|---|---|---|---|---|
| TQ415 | 4.7 | 14.0 | 60 | 475 | 385 | 770 | 660 | NG |
| TQ420 | 4.7 | 18.0 | 80 | 630 | 385 | 770 | 660 | NG |
| TQ4X20** | 4.7 | 18.0 | 80 | 695 | 385 | 770 | 660 | NG |
| TQ425 | 4.7 | 23.0 | 100 | 755 | 385 | 770 | 660 | NG |
| TQ4X25** | 4.7 | 23.0 | 100 | 810 | 385 | 770 | 660 | NG |
| TQ430 | 4.7 | 28.0 | 122 | 960 | 510 | 880 | 660 | NG |
| TQ4X30** | 4.7 | 28.0 | 122 | 1050 | 510 | 880 | 660 | NG |
| TQ435 | 4.7 | 32.0 | 140 | 1050 | 510 | 880 | 660 | NG |
*Based on Australian Gas Association’s results calculated in accordance with the testing methodology in AS/NZS5263.1.6:2016.
**Extra air models are designed to have Braemar add-on cooling system added.
Every single Braemar ducted gas heating unit is made from premium grade materials and supported by a comprehensive factory-backed warranty. Our industry standard 7 year comprehensive warranty** for residential ducted gas heating also comes with a 10 year heat exchanger and burner warranty.
**The 7 year comprehensive warranty is available exclusively (i.e. only) if the product is purchased from Seeley International participating dealers. If it is not, then the warranty period, when the product is used for personal, residential household purposes, is 5 years. In commercial applications (when the product is used for keeping people warm), the warranty period is 5 years, and it is 1 year for non-domestic heating applications. The warranty has terms and conditions, including the requirement for regular servicing of the product in accordance with the owner’s manual. In the fourth year the service must be performed by Seeley International or its appointed nominee.
Harness the power power of Braemar Gas Heating
A reputation built on quality and endurance
Founded in 1938, Braemar remains one of Australia’s most recognised and trusted brand names today.
Braemar warms the hearts and homes of Australians, providing total climate control in every home.
MagIQtouch®
Next Generation Controller
Control the temperature, fan speed and many more features on a user friendly touch screen. The discreet and modern design will blend seamlessly into the décor of your home.
